| Model | ELS-ZL10P |
| Working principle | Photoelectric sensor |
| Housing style | Square |
| Optical working principle | Diffuse reflection |
| Detection Range | 5~100mm |
| Light Source | Red Laser 650nm, Class 1 |
| Spot Size | Ø 1.0 mm / 0.10 m |
| Indicator light | Output function: Orange LED, Operating status: Green LED |
| Sensitivity Adjustment | 4 turns potentiometer |
| Switch Mode | L.on (light entry action) /D.on (light blocking action) can be switched |
| Output Mode | PNP open collector |
| Response Time | 0.33ms |
| Switching frequency | 6.06 kHz |
| Repeatability | ≤5% |
| Hysteresis | ≤5% |
| Operating Voltage | 10~30V DC±10% |
| Current Consumption | ≤35mA |
| Residual Voltage | ≤2.0V (100mA) |
| Load Current | ≤1.5V (100mA) |
| Insulation Resistance | ≥50MΩ (500VDC) between power terminal and housing |
| Withstand Voltage | 1000VAC (50/60Hz), 1 minute between the power terminal and housing |
| ProtectiOn Circuit | Short circuit protection/reverse polarity protection |
| Operating temperature | -10~50℃(without freezing) |
| Storage Temperature | -10~70℃(no freezing) |
| Operating humidity | 35~85%RH (no condensation) |
| Storage Humidity | 35~95%RH(no condensation) |
| Ambient light | Incandescent lamp ≤3000 Lux; LED lamp ≤1000 Lux |
| Vibration Resistance | 10~55Hz, amplitude 1.5mm, X, Y, Z axis, 2 hours each |
| Protection rating | IP67 |
| Maximum Tightening Torque | 0.5 Nm or less |
| Connection Method | 2M/ 4-core cable |
| Dimensions | 11.0 x31.0 x20.0 mm |
| Material | ABS+ fiberglass |
| Weight | 0.049 kg |
| Accessories | Bracket, screws |
