I. Giới thiệu
II. Thông số
| Product | TDS meter, EC controller |
| Model | SUP-TDS210-C |
| Measure range | 0.01 electrode: 0-20.00us/cm |
| 0.1 electrode: 0.2-200.0us/cm | |
| 1.0 electrode: 2-2000us/cm | |
| 10.0 electrode: 0.02-20ms/cm | |
| Accuracy | ±2%FS |
| Measuring medium | Liquid |
| Temp compensation | NTC10K/PT1000 Manual/ Auto temperature compensation |
| Temperature Range | -10-130℃ |
| Communication | RS485, Modbus-RTU |
| Signal output | 4-20mA, maximum loop 750Ω, 0.2%FS |
| Power supply | AC220V±10%, 50Hz/60Hz DC24V±20%, ≥6W |
| Relay output | 250VAC, 3A |
| Relative humidity | (10~85)%RH |
| Operation temperature | 0~60℃ |
| Operation condition | Temperature: 15~65℃ Relative humidity: (5~95)%RH |
III. Nguyên lý đo
IV. Hình ảnh
